Broad bean peeling machine introduction:
Broad bean peeling machine is designed to peel dried broad bean, soy bean, pea, mung bean, lentil and other beans. Win Tone Machinery designs a kind of special abrasive disk to peel the skin of the beans. The operator can adjust the distance of the abrasive disks according to different sizes of beans to peel beans skin. Then there is blower to separate the skin from the peeled beans. It can reduce the bean kernels broken rate and improve the working efficiency. The external material of the broad bean peeling machine is made of stainless steel.
Broad bean peeling machine can work as the single machine as below:
MTPS broad bean peeling machine technical parameter: (Letter A means external air blower. Letter B means internally installed air blower)
|
Model |
Emery Roll Diameter (mm) |
Emery Roll Length (mm) |
Spindle Speed （r/min） |
Yield （t/h） |
Power （kW） |
Air Volume （m³/h） |
Size (L*W*H) (mm) |
|
MTPS-18D/A |
Φ180 |
660 |
1300 |
1～1.5 |
22 |
1370×700×1900 |
|
|
MTPS-18D/B |
Φ180 |
660 |
1300 |
1～1.5 |
22 |
1500-1800 |
1410×1220×2030 |
|
MTPS-25D/A |
Φ240 |
660 |
1050 |
2-3 |
30 |
1515×660×2100 |
|
|
MTPS-25D/B |
Φ240 |
660 |
1050 |
2-3 |
30 |
1800-2100 |
1515×1220×2100 |
Workshop Processing for Bean Bran Removing Machine:
Shown at Exhibition Hall:
Bean bran removing machine end products:
Peeled Lentil:
Peeled Mung Bean:
Peeled Chickpea:
Peeled Peas:
Peeled Soybean:
Application Overseas (Part) :
Canada 120T/Day Lentil Peeling Project:
24T/Day Mung Bean Peeling Line in Thailand:
2T/Hour Lentil Peeling Line in Russia:
2T/Hour Lentil Peeling Line in Kazakhstan:
1T/Hour Lentil Peeling Line in Ethiopia:
2T/Hour Lentil Peeling Line in Ethiopia:
Pakistan 20 Sets of Chickpea Peeling Machines Delivery:
